Value Collection MSC-62148812 90 Degree Street Elbow 3/4 in

Product Description

The VALUE COLLECTION MSC-62148812 is a 3/4 inch malleable iron 90 degree street elbow finished in black and rated Class 150. Street elbows differ from standard elbows in that one end is a male threaded connection and the other is female threaded, allowing a direct connection without a separate nipple. This fitting is suited for low- to moderate-pressure piping systems carrying gas or liquid at pressures up to 300 psi. Plumbers, pipefitters, and mechanical contractors use this fitting when routing black iron pipe through tight spaces or when transitioning direction close to a valve or other threaded component.

This 90 degree street elbow is used in residential and commercial piping systems including natural gas distribution, steam, air, and water lines where black malleable iron fittings are required. The threaded end connections conform to standard NPT dimensions for compatibility with common black iron pipe sizes. The black finish is typical for gas piping applications and provides a baseline level of corrosion resistance in dry indoor environments.

Key Features

• 90 degree street elbow configuration with one male and one female NPT threaded end
• 3/4 inch fitting size for use with 3/4 inch black iron pipe
• Malleable iron construction rated Class 150
• 300 psi liquid and gas pressure rating
• Black finish suitable for gas piping and mechanical systems

Compatibility

Designed as an OEM-style replacement or new-installation fitting for 3/4 inch NPT threaded black iron piping systems in residential and commercial gas, steam, air, and liquid applications.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes, IFGC, and IPC requirements. Thread all connections using appropriate pipe thread sealant or tape rated for the intended service medium. Ensure the piping system is fully depressurized and isolated before removing or installing any fitting. Inspect threads for damage before assembly and do not overtighten, as malleable iron fittings can crack under excessive torque.
