Value Collection KG-1T1-0032-M1 Pipe Plug Immersion Heater

Product Description

The VALUE COLLECTION KG-1T1-0032-M1 is a single-element pipe plug immersion heater designed to heat liquids directly within a tank, pipe, or vessel. Rated at 500 watts and 120 volts single phase, this unit delivers 43 watts per square inch across a 6.375-inch immersion length. The plug body and element housing are constructed from stainless steel, providing corrosion resistance in water, mild chemical, and process fluid applications. A built-in thermostat is included for temperature control. This heater is installed by maintenance technicians, plumbers, or industrial service professionals working on fluid heating systems.

This immersion heater suits residential and light commercial applications where a compact, low-wattage heating element is needed inside a tank or reservoir. The standard housing and 1-inch NPT plug connection allow straightforward installation into existing threaded fittings on tanks or process vessels. Single-phase 120-volt power makes it compatible with standard branch circuits without requiring a dedicated high-voltage supply.

Key Features

• 500-watt output at 120 volts single phase for low-demand fluid heating
• 6.375-inch immersion length suits compact tanks and vessels
• Stainless steel plug and element construction for corrosion resistance
• 43 watts per square inch watt density for moderate-temperature applications
• 1-inch NPT connection for direct installation into standard threaded fittings
• Integrated thermostat for automatic temperature regulation

Compatibility

Designed as an OEM-style replacement or direct-install pipe plug immersion heater for tanks and vessels with a 1-inch NPT threaded port on single-phase 120-volt circuits.

Installation Notes

Installation should be performed by a qualified electrician or licensed plumber in accordance with NEC requirements for electric heating equipment. Drain and depressurize the tank or vessel and disconnect all electrical power before removing or installing the heater. Apply thread sealant rated for the fluid type to the NPT threads before installation, and do not over-tighten the plug into the fitting. Confirm the branch circuit ampacity and overcurrent protection are rated appropriately for the connected load before energizing.
