Value Collection IEH5100 Sex Bolt Brass 10-32 Unf Flat Head

Product Description

The VALUE COLLECTION IEH5100 is a brass sex bolt binding post designed for fastening applications that require a flush, tamper-resistant connection. The flat head accepts a Phillips drive and sits flush with the mating surface when installed. The chrome-plated finish provides a clean appearance and added surface protection. This binding post features a 10-32 UNF thread, an overall length of 1.56 inches, a barrel length of 1 inch, and a thread engagement length of 0.313 inches. These fasteners are commonly installed by maintenance technicians, fabricators, and fixture builders in light industrial and commercial settings.

Sex bolt binding posts like the IEH5100 are used where two panels or materials must be joined with a through-bolt assembly that allows disassembly without tool access from both sides being strictly required. Common applications include binder assembly, display fixture construction, menu board fabrication, and panel fastening. The tamper-resistant design discourages unauthorized disassembly in public-facing or security-sensitive installations. The brass base material offers good corrosion resistance and machinability, making it suitable for both indoor and light outdoor environments.

Key Features

• 10-32 UNF thread standard for broad compatibility with standard screw posts
• Flat head profile seats flush with the surface for a clean, low-profile finish
• Phillips drive for installation with standard hand or power tools
• Brass construction with chrome-plated finish for corrosion resistance and appearance
• Tamper-resistant design limits unauthorized disassembly in public or secured locations
• Overall length of 1.56 inches with a thread length of 0.313 inches

Compatibility

Designed as a standard 10-32 UNF sex bolt binding post replacement or new-install fastener for panel assemblies, binders, display fixtures, and similar applications requiring through-bolt clamping with a flush head.

Installation Notes

Installation is performed by inserting the barrel through the mating panels and threading the screw post into the barrel from the opposite face. Use a Phillips screwdriver or bit driver to tighten. Do not overtighten, as brass threads can strip under excessive torque. Verify panel thickness is compatible with barrel length before installation.
