Value Collection BD-L70S-200- Cartridge Fast-acting Fuse 200A

Product Description

The VALUE COLLECTION BD-L70S-200- is a cartridge-style fast-acting fuse rated at 200 amps. It provides overcurrent protection in industrial and commercial electrical systems where rapid response to fault conditions is required. The fuse measures 5-3/32 inches in overall length and 1-1/2 inches in diameter, fitting standard cartridge fuse holders of that size class. With an interrupting capacity of 200 kA at AC and 20 kA at DC, it handles high available fault currents common in commercial distribution panels and motor control centers. Licensed electricians and electrical maintenance technicians are the primary installers.

This fuse is suited for use in commercial and industrial electrical distribution equipment, motor control centers, disconnect switches, and fused panelboards where a 200A fast-acting cartridge fuse is specified. Its fast-acting timing characteristic makes it appropriate for protecting conductors and equipment that do not require a time-delay fuse to ride through motor inrush or transformer inrush current. Single-unit packaging makes it practical for service replacement applications.

Key Features

• 200A ampere rating for high-current circuit protection
• Fast-acting fuse timing for rapid fault clearing
• 200 kA interrupting capacity at AC and 20 kA at DC
• Cartridge body type fits standard cylindrical fuse holders
• CSA certified under File LR29862-99 and UL Recognized under File E71611
• Overall length of 5-3/32 inches and diameter of 1-1/2 inches for dimensional compatibility

Compatibility

Designed as a replacement cartridge fast-acting fuse for standard 1-1/2 inch diameter cylindrical fuse holders rated for 200A class fuses in commercial and industrial electrical equipment.

Installation Notes

Installation must be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the circuit completely before removing or installing the fuse. Verify the fuse holder is rated for the interrupting capacity of this fuse before installation. Confirm the fuse holder interior dimensions match the 5-3/32 inch length and 1-1/2 inch diameter of this cartridge before seating.
