Value Collection BD-7560-1 Cartridge Fast-acting Fuse 30A

Product Description

The VALUE COLLECTION BD-7560-1 is a cartridge-style, fast-acting fuse rated at 30 amps. It is constructed with a glass body that allows visual confirmation of a blown element without removing the fuse from its holder. At 0.875 inches overall length and 0.25 inches in diameter, this is a compact mini-form fuse suited for low-current branch circuit and equipment protection applications. Electricians and electronics technicians install this type of fuse in fuse holders, control panels, and inline fuse blocks where fast-acting overcurrent protection is required and space is limited.

This fuse is used in residential, commercial, and light industrial electrical applications where a fast-acting response to overcurrent events is needed. Typical installations include control circuit boards, small appliance protection, HVAC control wiring, and instrumentation panels. The glass body construction is common in legacy panel designs and retrofit applications. This fuse is sold in a package quantity of 5 units, making it practical for service technicians carrying spares on the job.

Key Features

• Fast-acting fuse timing for immediate response to overcurrent conditions
• Glass body construction allows visual inspection of fuse element without removal
• Mini cartridge form factor at 0.875 inches OAL and 0.25 inches diameter
• 30-amp rating suitable for control circuit and light equipment protection
• Packed in quantities of 5 for convenient field stocking

Compatibility

Designed as a standard-form replacement for mini cartridge fast-acting fuses measuring 0.25 inches in diameter and 0.875 inches in overall length, compatible with fuse holders and panel blocks accepting this body size.

Installation Notes

Installation should be performed by a qualified electrician. Always de-energize and lock out the circuit before replacing a fuse. Confirm that the replacement fuse amperage and voltage rating match the original equipment specification before installation. Never substitute a higher-amperage fuse to bypass a recurring overcurrent condition without first diagnosing the root cause.
