Value Collection BD-23085 Female Wire Disconnect 22-18 Awg

Product Description

The VALUE COLLECTION BD-23085 is a fully insulated female push-on wire disconnect terminal designed for fast, tool-free electrical connections in control wiring and low-voltage circuit applications. Constructed with a nylon insulating body, this terminal accepts 22 to 18 AWG wire and features a 1/4 inch tab width for a secure push-on fit. The fully insulated design reduces the risk of accidental contact with energized conductors. Electricians, HVAC technicians, and other trades use these terminals when terminating control wires at relays, contactors, sensors, and similar components. Each package contains 25 pieces.

These female disconnect terminals are suited for residential and light commercial electrical and HVAC control wiring. Common applications include connecting wire leads to relay coil terminals, fan motor capacitor tabs, thermostat sub-base connectors, and control board terminal strips where a 1/4 inch push-on tab is specified. The 22-18 AWG wire range covers most standard control circuit conductors used in these installations.

Key Features

• Push-on connection style for fast, tool-free termination
• Fully insulated nylon body for protection against accidental conductor contact
• Compatible with 22 to 18 AWG wire
• 1/4 inch tab width fits standard push-on relay and contactor terminals
• Sold in a pack of 25 pieces

Compatibility

Designed as a general-purpose replacement or stocking terminal for control wiring applications requiring a fully insulated female push-on disconnect with a 1/4 inch tab width and 22-18 AWG wire compatibility.

Installation Notes

Installation is performed by licensed electricians or qualified HVAC technicians. Always de-energize the circuit and verify absence of voltage before terminating or removing disconnect terminals. Strip wire to the length specified by the terminal crimp zone and use an appropriate ratcheting or hand crimp tool rated for the terminal type to ensure a secure mechanical and electrical connection. Follow applicable NEC requirements for wire gauge, insulation rating, and terminal compatibility at the point of use.
