Value Collection B92 65 Black 90 Street Elbow 2-1/2 in

Product Description

The VALUE COLLECTION B92 65 is a 2-1/2 inch black malleable iron 90 degree street elbow rated for Class 150 service. It features threaded end connections on both ends and is finished in black. This fitting redirects piping runs at a 90 degree angle and is rated for liquid and gas service at up to 300 psi. Licensed plumbers and pipefitters install this elbow in commercial and industrial piping systems. It carries multiple certifications including cULus listing, FM Approval, and compliance with EN 10242, ISO 7/1, GB/T 3287, GB/T 7306.2, and ABNT standards, making it suitable for a wide range of domestic and international project specifications.

This street elbow is used in residential and commercial plumbing, gas distribution, fire protection, and industrial fluid piping applications. The 2-1/2 inch threaded configuration fits standard NPT pipe runs where a 90 degree directional change is required. Its Class 150 malleable iron construction makes it appropriate for moderate-pressure gas and liquid service lines. It is packaged individually and ordered in single-unit quantities.

Key Features

• 2-1/2 inch threaded end connections for standard NPT pipe compatibility
• 90 degree street elbow configuration for tight-radius directional changes in piping runs
• Malleable iron construction with black finish for corrosion resistance in dry and low-moisture environments
• Rated at 300 psi for liquid and gas pressure service
• Class 150 fitting classification
• Multi-standard certified: cULus Listed, FM Approved, EN 10242, ISO 7/1, GB/T 3287, GB/T 7306.2, ABNT

Compatibility

Designed as an OEM-style replacement or new-installation fitting for Class 150 threaded malleable iron piping systems using 2-1/2 inch NPT connections.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing and mechanical codes. Shut off and depressurize the piping system completely before removing or installing any threaded fittings. Apply an approved thread sealant or PTFE tape to all male threads before assembly and tighten to hand-tight plus additional turns as required by the pipe material and application. Do not over-torque malleable iron fittings, as the material is not designed to withstand the same mechanical stress as forged steel.
