Value Collection ATF0481 Fly Cutter 1-1/8 in Head

Product Description

The VALUE COLLECTION ATF0481 is a single-bit fly cutter designed for use in milling operations where large-diameter facing cuts are required. Featuring a 1-1/8 inch head diameter and a 1/2 inch straight shank, this cutter accepts a 1/4 inch tool bit and holds one bit per cutter. It mounts in standard milling machine spindles or drill press chucks capable of accepting a 1/2 inch straight shank. Machinists and tool-and-die professionals use fly cutters like this for facing flat surfaces, cleaning up stock, and generating smooth surface finishes on ferrous and non-ferrous materials. The straight shank design allows straightforward installation in collets or Jacobs-style chucks without additional adapters.

This fly cutter is suited for light-duty facing work on benchtop and knee mills, drill presses configured for milling, and similar machine tool setups. It is commonly used in job shops, maintenance facilities, and vocational training environments. The 1-1/8 inch head diameter supports a moderate cutting radius appropriate for workpieces requiring clean, flat face passes in a single sweep. Tool bits are sourced separately, as bits are not included with this cutter body.

Key Features

• 1-1/8 inch head diameter for moderate-radius facing cuts
• 1/2 inch straight shank fits standard collets and Jacobs-style chucks
• Accepts 1/4 inch tool bits for flexible cutting geometry selection
• Single-bit design simplifies setup and bit replacement
• Straight shank type for direct chuck or collet mounting without adapters

Compatibility

Designed as an OEM-style replacement and standard fly cutter body for milling machines and drill presses equipped with a spindle or collet accepting a 1/2 inch straight shank.

Installation Notes

Installation is performed by a machinist or toolroom technician. Power down and lock out the machine before mounting or removing the cutter from the spindle. Ensure the shank is fully seated and the set screw or collet is tightened to the machine manufacturer's specification before operation. Tool bits are not included and must be installed and secured in the cutter body prior to use; inspect bit seating and clamping before each run.
