Value Collection A996643 Dowel Pin 8mm X 30mm Alloy Steel

Product Description

The VALUE COLLECTION A996643 is a flat vent pull out dowel pin manufactured from alloy steel to DIN 7979D standards. The pin measures 8 mm in diameter and 30 mm in overall length, with one rounded end and one threaded end for pull-out removal. Hardness is rated at Rockwell C 57-63, providing the wear resistance required for precision locating and alignment applications in tooling, fixtures, and mechanical assemblies. Installation and removal are straightforward for machinists and maintenance technicians working with standard DIN-compatible bored holes.

Flat vent pull out dowel pins are used in jigs, dies, molds, and machine fixtures where precise part alignment is critical and the pin must be removable without damage to the bore. The flat vent along the body allows air and fluid to escape during insertion, preventing hydraulic lock in blind-hole applications. The threaded pull end accepts a standard puller tool, making extraction clean and controlled even in tight assemblies. This pin is suited for both production tooling environments and maintenance repair operations.

Key Features

• DIN 7979D standard flat vent pull out design for reliable locating and alignment
• Alloy steel construction with Rockwell C 57-63 hardness for wear resistance
• One rounded end and one threaded end for pull-out extraction using a standard puller
• Flat vent body prevents hydraulic lock in blind-hole installations
• 8 mm diameter x 30 mm length suits common DIN-compatible fixture bores
• Sold in packages of 10 with a minimum order quantity of 1

Compatibility

Designed as a DIN 7979D-compliant replacement or stocking pin for use in any fixture, jig, die, or mold application requiring an 8 mm flat vent pull out dowel pin with a threaded pull end.

Installation Notes

Installation is typically performed by machinists or maintenance technicians using a press or mallet and a properly sized DIN-compatible bore. De-energize and lock out all machinery before inserting or removing dowel pins from live fixtures or tooling. To extract the pin, thread a standard M-series puller into the threaded end and draw the pin out axially to avoid bore damage. Inspect the bore for wear or damage before installing a replacement pin.
