Value Collection 6632-005 Push-to-connect Tube Fitting

Product Description

The VALUE COLLECTION 6632-005 is a push-to-connect tube-to-tube fitting manufactured from lead-free brass. It is designed to join two tubing runs without threaded connections or soldering, using a mechanical push-in mechanism for a secure, leak-resistant seal. The fitting accepts tubing with a 1 inch outside diameter and has a 1-1/8 inch thread size. An EPDM O-ring provides the primary seal, and the fitting is rated for a maximum working pressure of 200 psi. This type of fitting is installed by licensed plumbers and HVAC technicians in fluid-handling systems where fast, reliable connections are required.

This fitting is suited for residential and light commercial plumbing and HVAC hydronic applications where tube-to-tube connections are needed. The push-to-connect design speeds up installation in tight spaces or retrofit situations where soldering or threading is not practical. It is appropriate for use in water supply, distribution, and fluid transfer lines that fall within the 200 psi pressure rating.

Key Features

• Lead-free brass construction meets applicable no-lead plumbing requirements
• Push-to-connect design requires no soldering, threading, or special tooling for installation
• EPDM O-ring provides a durable, leak-resistant seal
• Rated to 200 psi maximum working pressure
• 1 inch OD tube compatibility with 1-1/8 inch thread size

Compatibility

Designed as an OEM-style replacement or new-installation fitting for tube-to-tube connections on systems using 1 inch OD tubing within the rated pressure range.

Installation Notes

Installation should be performed by a licensed plumber or HVAC technician in accordance with applicable IPC or local plumbing code requirements. Shut off and depressurize the system completely before making or breaking any connections. Tubing should be cut cleanly and squarely, with no burrs, before inserting into the push-to-connect fitting to ensure a proper seal. Do not exceed the 200 psi maximum working pressure rating for this fitting.
