Value Collection 51026 Snap Tite Pressure Test Plug

Product Description

The VALUE COLLECTION 51026 is a snap-style pressure test plug used to temporarily seal ports, openings, or pipe ends during pressure testing procedures. The plug features a 2-7/8 inch outer diameter and measures 1-3/16 inches in length. Its snap-tite design allows for fast, tool-free insertion and removal, making it well suited for leak-down tests, hydrostatic pressure tests, and system integrity checks. Plumbers, HVAC technicians, and pipefitters use this type of plug when isolating a section of piping or equipment to verify that the system holds pressure before returning it to service.

This plug is appropriate for use in residential and commercial plumbing, HVAC, and mechanical systems where a 2-7/8 inch opening must be sealed during testing. The snap-tite retention style provides a secure fit without requiring threading or additional hardware, speeding up the test setup process on the job. It is sold as a single unit and is a practical addition to a pressure testing kit used on new installations or service calls requiring pressure verification.

Key Features

• Snap-tite style allows quick insertion and removal without threading
• 2-7/8 inch outer diameter fits standard test port openings of that size
• Compact 1-3/16 inch length suits tight access areas
• Lightweight at 0.52 pounds for easy carry and handling
• Sold individually, one plug per package

Compatibility

Designed as an OEM-style replacement and general-use pressure test plug for pipe openings and test ports with a 2-7/8 inch inner diameter in plumbing, HVAC, and mechanical piping systems.

Installation Notes

This plug is typically installed by licensed plumbers or HVAC technicians performing pressure testing in accordance with applicable code requirements such as the IPC or IFGC. Before inserting the plug, ensure the system is depressurized and all energy sources are isolated. Snap the plug firmly into the port opening until it seats fully before applying test pressure. Remove the plug only after the system has been fully depressurized at the conclusion of the test.
