Value Collection 4HB1*1/2 Pipe Bushing 1x1/2 in 304 Ss

Product Description

The VALUE COLLECTION 4HB1*1/2 is a threaded pipe bushing designed to reduce a 1-inch female port down to a 1/2-inch male connection in pressurized piping systems. Constructed from 304 stainless steel, it resists corrosion in water, mild chemical, and process fluid applications. The MNPT x FNPT thread configuration allows the bushing to thread directly into a female-threaded fitting or valve body while accepting a male-threaded pipe or fitting on the outlet side. It carries a 150 psi pressure rating and weighs 0.254 pounds. Plumbers and pipefitters install this type of bushing wherever a pipe size reduction is needed within a threaded assembly.

This bushing is suited for residential and light commercial plumbing, HVAC hydronic systems, compressed air lines, and general industrial piping where 304 stainless steel is appropriate for the service fluid and temperature range. It provides a compact, inline size reduction without requiring a separate coupling and nipple combination, saving space in tight installations.

Key Features

• 304 stainless steel construction for corrosion resistance in wet and mildly corrosive environments
• MNPT x FNPT threaded ends for tool-based, leak-resistant assembly
• 150 psi pressure rating suitable for water, air, and compatible process fluids
• Reduces 1-inch female port to 1/2-inch male outlet in a single fitting
• Compact bushing profile fits flush inside existing female-threaded fittings

Compatibility

Designed as a standard threaded pipe bushing for use in 1-inch to 1/2-inch NPT piping assemblies where a 150 psi rated, stainless steel size reduction is required.

Installation Notes

Installation is performed by licensed plumbers or qualified pipefitters following applicable IPC and local plumbing code requirements. Shut off and depressurize the line completely before disassembling or installing any threaded fitting. Apply an appropriate thread sealant or PTFE tape to the male threads before assembly and tighten with a pipe wrench to a snug, leak-free fit. Do not over-torque stainless steel threads, as galling can damage the fitting and the mating port.
