Value Collection 4710302512 Aluminum 3-outlet Manifold

Product Description

The VALUE COLLECTION 4710302512 is a compact aluminum manifold designed to split a single inlet line into three outlet branches. It accepts a 1/4 inch or 1/2 inch FNPT inlet and delivers flow through three 1/4 inch FNPT outlet ports, making it a practical solution for distributing fluid or gas in tight plumbing and fluid-control applications. The body measures 1.5 inches in overall length, 1.5 inches in width, and 1.5 inches in height, keeping the footprint small for confined installations. At 1.84 pounds, it is lightweight enough for direct inline mounting without additional support. Outlet ports are spaced 3/8 inch center to center, allowing parallel connections in a compact array. Licensed plumbers and fluid-system technicians are the primary installers.

This manifold suits residential and light commercial fluid distribution systems where a single supply line must feed multiple branch circuits or components simultaneously. Typical applications include hydronic heating branch connections, pneumatic control lines, water treatment distribution headers, and similar low-complexity fluid-splitting needs. The FNPT threading is compatible with standard pipe fittings widely available in plumbing and HVAC supply channels. The 5/8 inch mounting hole diameter allows optional surface mounting when inline installation is not preferred.

Key Features

• Dual inlet sizing accepts 1/4 inch or 1/2 inch FNPT connections for flexible supply-side hookup
• Three 1/4 inch FNPT outlet ports split a single supply into three branch lines
• Aluminum body construction keeps weight low and resists corrosion in clean fluid service
• Compact 1.5 x 1.5 x 1.5 inch envelope fits restricted installation spaces
• 3/8 inch outlet center-to-center spacing allows dense parallel fittings
• 5/8 inch mounting hole diameter supports optional panel or bracket mounting

Compatibility

Designed as an OEM-style replacement or new-installation manifold for systems using standard FNPT pipe fittings in 1/4 inch and 1/2 inch sizes.

Installation Notes

Installation should be performed by a licensed plumber or qualified fluid-systems technician in accordance with applicable local codes and IPC guidelines. Shut off and depressurize the supply line fully before removing any existing fittings or installing this manifold. Apply thread sealant tape or paste rated for the fluid service to all FNPT connections and tighten to hand-tight plus the appropriate number of turns per fitting manufacturer guidance. Do not overtighten aluminum-threaded fittings, as excess torque can crack the body.
