Value Collection 383-8322 GL-16 Single-point Tool Bit

Product Description

The VALUE COLLECTION 383-8322 is a GL-16 style single-point tool bit designed for metal turning operations on manual and CNC lathes. It features a solid carbide tip rated at grade C2, suited for general-purpose turning and facing applications where wear resistance and edge retention matter. The shank measures 1 inch in height and 1 inch in width, with an overall length of 7 inches. A 1/32-inch nose radius is ground into the tip for controlled surface finish during cuts. This tool is configured for left-hand cutting direction. It is typically installed by machinists and toolroom technicians in production and job-shop environments.

This tool bit is built for turning and facing to shoulder operations, as well as work performed close to chuck jaws where clearance is limited. The offset end-cutting geometry of the GL style allows the operator to run the tool up close to a shoulder or chuck face without interference. It is suited for use on steel, cast iron, and similar ferrous materials in standard lathe tool holders that accept 1-inch square shank tooling. The left-hand cutting direction means the tool advances from left to right relative to the workpiece spindle.

Key Features

• GL-16 industry-standard offset end-cutting geometry for shoulder and chuck-proximity work
• C2 grade solid carbide tip for wear resistance on ferrous metals
• 1 inch by 1 inch square shank fits standard 1-inch tool holders
• 1/32-inch nose radius for controlled surface finish
• 7-inch overall length provides rigidity and reach in standard lathes
• Left-hand cutting direction for right-to-left feed operations

Compatibility

Designed as a direct-fit replacement or addition for standard lathe tool holders accepting a 1-inch square shank single-point tool bit in the GL-16 industry-standard configuration.

Installation Notes

Installation is performed by a machinist or toolroom technician. Power down and lock out the lathe before seating or adjusting the tool bit in the holder. Ensure the shank is fully seated and clamped squarely to prevent chatter or tool pullout during cuts. Follow applicable shop safety standards and machine manufacturer guidelines for tool height and overhang.
