Value Collection 2400-1201 Rocker Tool Post Lathe

Product Description

The VALUE COLLECTION 2400-1201 is a rocker-style tool post designed for metal lathes with a swing of 12 inches or under. It mounts to the compound rest and allows the cutting tool to be angled by rocking and locking the post body, giving machinists a fast way to set tool height without shimming. The opening measures 2-1/2 x 1/2 inches, the overall height is 3-1/4 inches, and the base plate is 2 x 2 inches with a 1/4-inch thickness. At 2 pounds, it is a solid, no-frills workhorse suited for benchtop and mid-size engine lathes in shop or maintenance environments.

This rocker tool post fits lathes in the 12-inch-and-under swing class, making it a practical choice for small to mid-size turning operations in machine shops, maintenance facilities, vocational training programs, and toolroom environments. It is intended for single-point turning, facing, and boring operations where quick tool adjustments are needed. No coolant-through capability is included, so it is best suited for dry or flood-coolant-from-the-outside setups.

Key Features

• Rocker adjustment allows tool height setting without adding or removing shims
• 2-1/2 x 1/2 inch tool opening accommodates common single-point tool holders and bits
• 3-1/4 inch overall height fits standard compound rest T-slots on 12-inch-swing-class lathes
• 2 x 2 x 1/4 inch base plate provides stable, flat contact with the compound rest
• No through-coolant design simplifies cleaning and maintenance

Compatibility

Designed for use on metal lathes with a swing capacity of 12 inches or under. Confirm T-slot dimensions and stud size on the compound rest before ordering to ensure proper fit.

Installation Notes

Installation is performed by a machinist or qualified lathe operator. Power down and lock out the lathe spindle before removing or installing any tool post. Seat the base plate flat on the compound rest, thread the stud through the T-slot, and tighten the nut to secure the post without warping the plate. Rock the post to the desired tool angle and clamp firmly before taking any cut.
