Value Collection 12C5 12D Common Nail 9 Gauge Ring Shank

Product Description

The VALUE COLLECTION 12C5 is a 12D common nail designed for structural framing, sheathing, and general construction fastening applications. Built from Grade 2 steel with a bright finish, this nail features a ring shank profile that increases withdrawal resistance compared to a smooth shank. At 9 gauge and 3-1/4 inches overall length, it drives cleanly by hand or pneumatic nailer and holds securely in dimensional lumber, engineered wood, and OSB. Carpenters, framers, and general contractors rely on this nail size for wall framing, floor decking, and roof sheathing work governed by standard residential and light commercial building codes.

This nail is suited for residential and light commercial construction where a 12D common specification is called for. Typical applications include stud-to-plate connections, rim joist fastening, blocking, and structural sheathing attachment. The ring shank geometry distributes withdrawal load along the shank rather than concentrating it at the tip, making it a reliable choice in applications where vibration or seasonal wood movement is a factor. Installation follows standard framing practices as outlined in building code schedules for nail size and spacing.

Key Features

• Ring shank profile increases withdrawal resistance compared to smooth shank nails
• Grade 2 steel construction for consistent hardness and driveability
• Bright finish suitable for interior and dry-service framing applications
• 12D penny size at 3-1/4 inches OAL matches standard framing nail schedules
• 9 gauge diameter provides solid holding power in dimensional lumber and engineered panels
• Flat head design seats flush and distributes surface load effectively

Compatibility

Designed as a standard 12D common nail for use in residential and light commercial framing applications where a 3-1/4 inch, 9 gauge ring shank nail is specified.

Installation Notes

Installation is performed by carpenters and framers using a framing hammer or pneumatic nail gun rated for 12D common nails. Verify nail size and spacing requirements against the applicable building code nail schedule before fastening. Bright finish nails are intended for interior or protected applications and are not recommended for exposure to moisture or corrosive environments. Follow all applicable local building codes and safety protocols when driving nails overhead or near structural connections.
