Value Collection 1110MSB 10-32 X 5/8 Binding Head Slotted Screw

Product Description

The VALUE COLLECTION 1110MSB is a 10-32 x 5/8-inch binding head machine screw designed for general mechanical fastening in trade and industrial applications. Built from steel with a zinc-plated finish, this screw meets ASME B18.6.3 and SAE J82 standards for dimensional accuracy and material grade. The binding head profile provides a low-profile, wide-bearing surface that is well suited for wire retention and panel assembly work. The slotted drive accepts a standard flat-head screwdriver. Licensed electricians, HVAC technicians, and mechanical contractors rely on this fastener type when assembling control panels, junction boxes, and equipment enclosures.

This screw is used in light-gauge sheet metal assembly, electrical panel work, HVAC equipment cabinets, and similar applications where a binding head fastener is specified. The 10-32 thread is a fine-pitch unified thread commonly found in instrumentation, control boards, and enclosure hardware. Length is measured under the head at 5/8 inches. Sold individually by package, with a minimum order quantity of 100 pieces per order.

Key Features

• Thread size 10-32 fine-pitch unified thread for secure engagement in tapped holes
• Binding head profile provides wide bearing surface, commonly used in wire-clamp and panel applications
• Slotted drive compatible with standard flat-blade screwdrivers
• Steel construction with zinc-plated finish for corrosion resistance in indoor environments
• Meets ASME B18.6.3 and SAE J82 dimensional and material grade standards
• Length under head: 5/8 inches

Compatibility

Designed as a standard 10-32 binding head machine screw for use in any application specifying an ASME B18.6.3 compliant fastener of this thread size and head style.

Installation Notes

Install using a flat-blade screwdriver matched to the slot width to avoid cam-out and fastener damage. Ensure the receiving hole is properly tapped to 10-32 before driving. De-energize any electrical panel or equipment before installing fasteners in live enclosures, following applicable NEC guidelines. Do not overtighten — snug to contact with the mating surface is sufficient for most light-gauge panel applications.
