Value Collection 111059106 SPG632 Carbide Turning Insert

Product Description

The VALUE COLLECTION 111059106 is a solid carbide turning insert in the SPG style, designed for single-point turning operations on CNC lathes and manual turning centers. This uncoated bright-finish insert carries ANSI code SPG632 and ISO code SPG190408, with a 3/4 inch inscribed circle and a 1/32 inch corner radius. The square insert shape provides a 90-degree included angle, an 11-degree relief angle, and a positive side clearance geometry with a flat-top chip breaker configuration. It is held in place by a clamp-style toolholder and is suited for use with C5 and C6 material grade toolholding systems. Machinists and CNC operators install this insert when working with ferrous workpiece materials classified under primary material code P.

This insert is intended for precision turning applications in machine shops, production facilities, and maintenance environments. The SPG632 geometry fits standard clamp-style insert toolholders designed for square inserts with a positive clearance (P clearance code) and G tolerance class. It is appropriate for light to moderate cuts on steel and similar ferrous materials. The uncoated carbide construction makes it a practical choice when coating is not required by the application or when re-grinding is planned. Sold individually with a minimum order quantity of 10 units.

Key Features

• Solid carbide construction, uncoated bright finish for versatile ferrous turning
• ANSI insert code SPG632, ISO insert code SPG190408 for precise toolholder matching
• 3/4 inch (0.750 inch) inscribed circle with 3/16 inch insert thickness
• 1/32 inch (0.0315 inch) corner radius for controlled surface finish
• Positive side clearance geometry with flat-top chip breaker
• Clamp-style holding method compatible with standard SPG square insert seats

Compatibility

Designed for use in clamp-style toolholders accepting SPG-style square turning inserts with a positive clearance angle, G tolerance class, and 632 ANSI size code.

Installation Notes

This insert is installed and replaced by machinists or CNC operators. Power down and lock out the machine before seating or removing inserts. Use the appropriate torque wrench on the clamp screw to secure the insert without cracking the carbide substrate. Inspect the insert seat and clamp for wear or debris before installation to ensure proper seating and consistent tool geometry.
