Value Collection 0814MSB 8-32 X 7/8 in Binding Head Slotted Screw

Product Description

The VALUE COLLECTION 0814MSB is a binding-head machine screw designed for general-purpose fastening in light-assembly, electrical, and mechanical applications. Sized at 8-32 thread with a 0.875-inch length under head, this screw features a slotted drive and a low-profile binding head that provides a broad clamping surface suited for securing conductors, terminal blocks, and panel components. Constructed from steel with a zinc finish, it meets the dimensional and mechanical requirements of ASME B18.6.3 and SAE J82 Grade J. This item is sold in a minimum order quantity of 100 units per order.

This screw is a standard fit for residential and commercial electrical panels, control enclosures, junction boxes, and light mechanical assemblies. The binding head style is commonly specified where a flat or oval underhead bearing surface is needed to retain wiring or lug hardware without damage. Electricians, HVAC control panel assemblers, and general maintenance technicians are the primary installers. The slotted drive accommodates standard flat-blade screwdrivers available in any trade toolkit.

Key Features

• 8-32 UNC thread for compatibility with standard tapped holes in electrical and mechanical hardware
• Binding head profile provides a wide, flat underhead bearing surface ideal for conductor retention
• Slotted drive works with standard flat-blade screwdrivers — no specialty tooling required
• Steel construction with zinc finish for corrosion resistance in typical indoor environments
• Meets ASME B18.6.3 and SAE J82 Grade J dimensional and mechanical standards
• Sold in multiples of 100 for consistent inventory stocking

Compatibility

Designed as an OEM-style replacement or stock fastener for any application requiring an 8-32 x 0.875-inch binding-head slotted machine screw per ASME B18.6.3 and SAE J82.

Installation Notes

Installation is performed with a standard flat-blade screwdriver sized to the slot width. When used in electrical enclosures or panels, de-energize and lock out the equipment before fastening per NFPA 70 (NEC) safe-work practices. Do not overtighten — binding-head screws in soft terminal or panel materials can strip threads or crack housings. Verify that mating tapped holes or nuts are rated for the 8-32 thread series before installation.
