Value Collection 0810MSB 8-32 Binding Head Slotted Machine Screw

Product Description

The VALUE COLLECTION 0810MSB is a binding head machine screw designed for general-purpose fastening in metal assemblies, panel work, and light structural applications. It features an 8-32 thread size with a 5/8-inch length under head and a slotted drive for use with a standard flat-blade screwdriver. The binding head profile sits low and wide, distributing clamping load over a broader bearing surface than a pan or round head. Manufactured from steel with a zinc finish, the 0810MSB meets ASME B18.6.3 and SAE J82 standards. This fastener is sold in multiples of 100 units per order.

This screw is suited for use in electrical enclosures, control panels, HVAC equipment housings, and sheet metal assemblies where a low-profile binding head is required. The slotted drive is compatible with standard manual and power screwdrivers. The zinc coating provides a basic level of corrosion resistance appropriate for indoor and protected environments. Technicians in HVAC, electrical, and light mechanical trades will find this fastener relevant for panel cover attachment, terminal strip mounting, and equipment frame assembly.

Key Features

• 8-32 thread size, 5/8-inch length under head for precise fitment in threaded assemblies
• Binding head profile provides a wide bearing surface and low-profile seating
• Slotted drive accepts standard flat-blade screwdrivers and bits
• Steel construction with zinc finish for basic corrosion resistance in dry or protected environments
• Meets ASME B18.6.3 and SAE J82 fastener standards
• Sold in quantities of 100 units minimum, packaged as 1 unit per package

Compatibility

Designed as a standard inch-series machine screw for use in any threaded hole or nut accepting an 8-32 thread, including equipment chassis, electrical panel hardware, and light mechanical assemblies requiring a binding head fastener.

Installation Notes

Installation is performed with a flat-blade screwdriver or slotted bit driver sized to the screw head. Ensure the mating thread is clean and free of debris before driving. Do not overtighten into thin sheet metal or plastic standoffs, as the binding head can generate significant clamping force. De-energize any electrical equipment before installing or removing fasteners on live panels, in accordance with applicable NFPA 70 lockout/tagout procedures.
