Utica Boilers U90205003210410 UB90-50-IV Nat Gas Condensing Direct Vent Boiler W/Taco 50 MBH

Product Description

The UTICA BOILERS U90205003210410 UB90-50-IV is a gas-fired condensing boiler designed for hot water systems. It features a stainless steel premix burner and is suitable for natural gas or propane. With an AGA input rating of 50 MBH and a DOE heating capacity of 45 MBH, this boiler achieves a 90 percent AFUE rating. It has a water content of 2.6 gallons.

• Energy Star Rated
• Electronic Ignition
• Induced Draft

Product Highlights

The UTICA BOILERS UB90-50-IV is a 50 MBH natural gas condensing boiler with a 90% AFUE rating, ideal for efficient home heating.

Product Information

Standard Information

• Brand: UTICA BOILERS
• Manufacturer Part Number: U90205003210410

Technical Specifications

• AFUE Rating: 90 Percent
• AGA Input Rating: 50 MBH
• Applicable Standard: ASME H, AHRI, CSA (Canada and US)
• Burner Type: Stainless Steel Premix
• CATALOG NUMBER: U90205003210410
• Category: HVAC/R & Fans
• DOE Heating Capacity: 45 MBH
• Gas Connection: 1/2 Inch Threaded
• Gas Type: Natural/Propane
• Manufacturer Name: Utica Boilers
• Manufacturer Part Number: UB90-50-IV
• Pressure Rating: 50 PSI
• Relief Valve Details: 30 PSI Relief Valve Supplied
• Return Connection: 1-1/4 Inch Threaded
• Series/Model: UB90
• Supply Connection: 1-1/4 Inch Threaded
• Type: Hot Water
• UNSPSC Code: 40102004
• Water Content: 2.6 Gallon
• Input Supply Rating: 120 Volt AC 60 Hertz 1-Phase 12 Amp
• Model: U90205003210410
• AHRI Number: 5339011
• Product Height (in): 36
• Gas Furnace Efficiency: 90%
• Product Length (in): 17.375
• Product Width (in): 17.75
• Electrical Phase: 1-Phase
• Exhaust Pipe: PVC
• Fuel Source: Natural Gas
• Gas Valve: Single Stage
• Load Connection: 1 1/4 inch
• Max Overcurrent Protection: 15 amps
• Primary Heating Capacity: 45,001 - 50,000 BTU
• Voltage: 120
