USP HD1714IF MiTek HD Series Face-Mount Hanger 1-3/4 x 16 14 ga Steel

Product Description

The USP HD1714IF is a MiTek HD Series face-mount hanger made from fourteen-gauge steel. It is built for heavy-duty applications, offering reliable support for headers, joists, and trusses. This hanger includes both round and diamond nail holes. These features provide design flexibility while achieving maximum load capacities.

• Made of fourteen-gauge steel with G90 finish
• Meets code requirements for various applications
• Designed for nominal lumber dimensions of one and three-fourth by fourteen inches

Product Highlights

This face-mount hanger is ideal for use in construction projects requiring strong and secure reinforcement for structural components.

Product Information

Standard Information

• Brand: USP
• Finish: G90 Galvanized

Technical Specifications

• Load Capacity: DF/SP (100) 3790 lb, DF/SP (115) 3920 lb, DF/SP (125) 4005 lb
• Overall Depth: 2.5 inches
• Overall Width: 1.81 inches
• Overall Height: 13.31 inches
• Compatible Joist Width: 1.75 inches
• Compatible Joist Height: 14 inches
• Material: Galvanized Steel
• Fastener Size: (28) 0.162 x 3-1/2 in (Header), (8) 0.148 x 1-1/2 in (Joist)
