Us Motors m055tze0092015b 1 Hp Opao Motor 1075 Rpm

Product Description

The US MOTORS m055tze0092015b is a 1 HP brushless permanent magnet (BPM) motor rated at 1075 RPM, designed for HVAC blower and fan applications. This fractional horsepower motor operates on 115/208-230 volt single-phase power at 60 Hz, with secondary 50 Hz capability, making it adaptable to a wide range of residential and light commercial equipment. The OPAO enclosure provides open protection for air-over cooling environments. Full load amperage is 12.4 amps at 115 volts and 7.8-7.2 amps at 208-230 volts. Insulation is Class B, and thermal protection is handled electronically within the motor. Licensed HVAC technicians are the primary installers for this type of replacement motor.

This motor is suited for residential and light commercial HVAC blower assemblies, condenser fans, and evaporator fan applications where an OPAO-enclosed, direct-drive fractional horsepower motor is required. The reversible rotation allows the installer to configure shaft direction to match the existing fan assembly without sourcing a separate part. The 48 frame size and Y shaft code are standard references used when cross-referencing OEM replacements in air handler and furnace blower sections.

Key Features

• 1 HP brushless permanent magnet motor with electronically managed thermal protection
• Reversible rotation for flexible installation configurations
• Multi-voltage operation: 115V or 208-230V single-phase, 60/50 Hz
• OPAO enclosure rated for open air-over cooling environments
• 48 frame, Y shaft code for standard OEM cross-reference fitment
• Ball bearings on both shaft end and opposite end for extended service life

Compatibility

Designed as an OEM-style replacement fractional horsepower blower motor for residential and light commercial HVAC systems requiring a 48-frame, 1 HP, 1075 RPM, OPAO-enclosed, brushless permanent magnet motor in a 115/208-230V configuration.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all power to the air handler or furnace before removing the existing motor. Verify shaft rotation direction, voltage tap selection, and frame alignment before securing the motor in place. Follow all applicable local codes and manufacturer wiring diagrams when reconnecting electrical leads.

Technical Specifications

• Horsepower: 1 HP
• Kilowatts: 0.8 kW
• Motor Type: Brushless Permanent Magnet (BPM), FHP
• RPM: 1075
• Voltage: 115/208-230 volts
• Full Load Amps: 12.4 A at 115V; 7.8-7.2 A at 208-230V
• Phase: Single-Phase
• Hertz: 60 Hz primary, 50 Hz secondary
• Poles: 10
• Number of Speeds: 1
• Frame: 48
• Shaft Code: Y
• Stack: 1.875 inches
• Enclosure: OPAO
• Rotation: Reversible
• Bearing Type (Shaft End): Ball
• Bearing Type (Opposite End): Ball
• Insulation Class: B
• Thermal Protection: Electronically Protected
• Ambient Temperature Rating: 40 degrees F
• Shipping Weight: 14 pounds

Standard Information

• Brand: US MOTORS
• Manufacturer Part Number: m055tze0092015b
