US Motors K055TEC8578012B 1880 .25 HP TEAO 825 RPM 460V 48Y Frame

Product Description

The US Motors K055TEC8578012B is a .25 HP HVAC motor ideal for both residential and commercial condenser fan applications. This unit has a totally enclosed air over design, extended studs, and a hubless lead end equipped with thirty-inch leads. It operates effectively with 370V capacitors and features Class B insulation.

• Permanent Split Capacitor
• Totally Enclosed Air Over Design
• Automatic Reset Thermal Overload Protection

Product Highlights

This motor is suitable for continuous duty and supports various applications including commercial condenser and residential cooling systems.

Product Information

Standard Information

• Model Number: K055TEC8578012B
• HP: 0.25

Technical Specifications

• RPM: 825
• Frame Size: 48Y
• Voltage: 460 V
• Motor Type: TEAO
• Phase Type: 1 - Permanent Split Capacitor
• Enclosure Type: TEAO
• Frequency Rating: 60 Hz
• Service Factor: 1.00
• Shaft Diameter: 0.5000 in
• Overall Length C Dimension: 11.6 in
• Thermal Protection: Automatic Reset
• Full Load Current: 1.00 A
• Shipping Weight: 15 lbs
