Us Motors k055kpp3345012b Fan Motor 1/2 Hp 1075 Rpm 115V

Product Description

The US MOTORS k055kpp3345012b is a Rescue-series permanent split capacitor (PSC) condenser fan motor rated at 1/2 horsepower and 1075 RPM. Built for HVAC replacement applications, it features a 5.6-inch frame diameter, OPAO (Open Air Over) enclosure, and a 4-speed winding with EZ-WIRE lead configuration for simplified field installation. The motor operates on 115 volts, 60 Hz, single-phase power and includes a 10 MFD / 370 VAC run capacitor. Rotation is counterclockwise (CCW) from the lead end, and the unit is reversible, giving technicians flexibility during installation. It ships with a single shaft configuration.

This motor is used in residential and light-commercial HVAC systems as a direct replacement for failed or underperforming condenser fan motors. The 4-speed winding and EZ-WIRE design make it a universal-style replacement suited for a wide range of OEM applications. Licensed HVAC technicians performing condenser section repairs or full fan motor replacements will find the reversible rotation and multi-speed capability particularly useful when matching original equipment specifications.

Key Features

• 1/2 HP output at 1075 RPM with 6-pole winding
• 4-speed configuration with EZ-WIRE lead arrangement for fast field wiring
• Reversible rotation — factory set CCW from lead end
• OPAO enclosure rated for outdoor condenser fan service
• Includes 10 MFD / 370 VAC run capacitor
• Single shaft design, 5.6-inch frame diameter

Compatibility

Designed as a universal OEM-style replacement PSC condenser fan motor for residential and light-commercial HVAC systems requiring a 1/2 HP, 1075 RPM, 115-volt, single-phase motor in a 5.6-inch frame diameter.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect and lock out all power to the condensing unit before removing the existing motor or capacitor. Verify rotation direction and speed tap selection against the original equipment wiring diagram before energizing. Secure all electrical connections per NEC requirements and confirm the run capacitor is properly rated and mounted before returning the system to service.

Technical Specifications

• Horsepower: 1/2 HP
• Speed: 1075 RPM
• Poles: 6
• Number of Speeds: 4
• Voltage: 115 volts
• Frequency: 60 Hz
• Phase: Single phase
• Run Capacitor: 10 MFD / 370 VAC
• Frame Diameter: 5.6 inches
• Enclosure: OPAO
• Rotation: CCW from lead end
• Reversible: Yes
• Shaft Configuration: Single shaft
• Wiring: EZ-WIRE

Standard Information

• Brand: US MOTORS
• Manufacturer Part Number: k055kpp3345012b
