Nidec HD10P2E Electric Motor 10 HP 1800 RPM 215T Frame 208-230-460V TEFC

Product Description

The Nidec HD10P2E Electric Motor offers 10 horsepower at 1800 RPM, making it suitable for various industrial applications. Designed with a 215T frame and 208-230/460 volts, this motor is built to handle demanding conditions.

• 10 horsepower motor
• 1800 RPM speed
• Three-phase operation

Product Highlights

This electric motor is efficient for pulp and paper plants, saw mills, mines, foundries, chemical plants, waste management facilities, and other harsh industrial environments.

Product Information

Standard Information

• Brand: Nidec
• MPN: HD10P2E
• Voltage: 208-230/460 Volts
• Material: Cast Iron
• Horsepower: 10 hp
• Speed: 1800 RPM
• Frame: 215T
• Enclosure: TEFC
• Phase: Three

Technical Specifications

• Amperage: 27.5-25.7/12.8
• Bearings Type: Ball/Ball
• Bearings Size: 6206-2Z-J/C3 / 6208-2Z-J/C3
• Motor Efficiency: 91.70%
• Insulation Class: F
• Service Factor: 1.15
• Duty: Hostile Duty
• Mounting: Horizontal/Footed
