Us Motors EU04 TEFC .5 HP 3-Phase 1725 RPM Motor

Product Description

The US MOTORS EU04 is a TEFC, 0.5 HP, 3-Phase, 1725 RPM motor designed for general-purpose applications. This premium efficient motor features a totally enclosed fan-cooled (TEFC) enclosure and Corro-Duty construction. It is suitable for various industrial and commercial uses requiring a reliable power source.

• General Purpose
• Three Phase
• Totally Enclosed Fan Cooled (TEFC)

Product Highlights

This US Motors TEFC motor delivers efficient performance with its robust design and premium components.

Product Information

Standard Information

• Brand: US MOTORS
• Manufacturer Part Number: EU04

Technical Specifications

• Brand: US Motors
• Frame: 56J
• Hertz: 60 Hz
• Phase: 3
• Voltage: 230/460 V
• Enclosure: TEFC
• RPM Range: 1701-1800 rpm
• Horsepower: 1/2 HP
• Enclosure Type: Totally Enclosed
• Full Load Amps: 8.4/4.1-4.3 FLA
• Service Factor: 1.15
• Insulation Class: F
• Mounting Location: C-Face Footless
• Motor RPM 60 Hertz: 1725 rpm
• RPM: 1725 rpm
• Manufacturers Part Number: EU04
• Rotation: REV
• Bearings Type: Ball / Ball
• Mounting: C-Face
• Model#: C063HNJ5058R13J
• Catalog#: C063HNJ5058R13J
• MODEL: EU04
• SKU: 6488548
• Dimension C: 11-5/16 in
