US Motors EC5411D ECM Refrigeration Motor 115/230 VAC

Product Description

The US Motors EC5411D is an electronically commutated motor (ECM) suitable for refrigeration applications. This motor functions on 115/230 VAC and provides power from four to twenty-five watts. It operates at a rotation speed of one thousand five hundred fifty to one thousand seven hundred twenty-five RPMs in a clockwise direction. Designed with a totally enclosed air over (TEAO) enclosure, it includes a quarter-inch threaded shaft.

• Operates on 115/230 VAC
• Rotation speed of 1550-1725 RPM
• Totally Enclosed Air Over (TEAO) enclosure

Product Highlights

This motor is ideal for refrigeration systems where reliability is crucial. It supports energy-efficient operations while providing durable performance in various temperature conditions.

Product Information

Standard Information

• Brand: US Motors
• Manufacturer Part Number: EC5411D

Technical Specifications

• Voltage: 115/230 VAC
• Horsepower: 4W-25W
• Amps: 0.22-0.75/0.15-0.45
• RPM: 1550-1725
• Rotation Type: Clockwise
• Enclosure: Totally Enclosed Air Over (TEAO)
• Shaft Diameter: 0.25 inches
• Bearing Type: Ball
• Speeds: 1
• Motor Type: ECM (Electronically Commutated Motor)
• Phase: Single
• Frequency: 60 Hz
• Insulation Class: B
• Number of Bearings: 2
• Approvals: UL Listed; UL Recognized
• Operating Temperature: -40°F to 130°F
• Shaft Length: 0.425 inches
• Weight: 2 lbs
• Motor HP: 3/100 HP
