Us Motors D2CM2JH 2 Hp Ac Motor 1725 Rpm 56H Odp

Product Description

The US MOTORS D2CM2JH is a capacitor-start, capacitor-run single-phase AC motor rated at 2 horsepower and designed for continuous-duty applications in industrial and commercial equipment. Running at 1725 RPM on a 56H frame, it operates on 115 volts or 208 to 230 volts, giving installers flexibility across common service voltages. The open drip-proof (ODP) enclosure suits indoor and semi-protected environments where airflow cooling is adequate. Full-load amperage is 20.0 amps at 115 volts and 11.3 to 10.0 amps at 208 to 230 volts. Class B insulation provides reliable thermal performance in standard ambient conditions. The rigid base mount ensures stable, low-vibration installation on equipment bases and equipment pads.

This motor is suited for replacement or new installation in compressors, pumps, conveyors, fans, and similar belt-drive or direct-drive loads that require a capacitor-start, capacitor-run configuration. The 56H frame is a common NEMA frame size found across a wide range of OEM and aftermarket motor applications in HVAC, pumping, and light industrial equipment. The dual-voltage wiring configuration makes it adaptable to both 115-volt residential circuits and 208 to 230-volt commercial panels without requiring a different motor at each service voltage.

Key Features

• Capacitor-start, capacitor-run design delivers high starting torque and efficient running performance
• Dual voltage rated at 115 volts and 208 to 230 volts for broad electrical compatibility
• NEMA 56H rigid base frame for secure, stable mounting on standard equipment bases
• ODP enclosure allows through-ventilation cooling in protected indoor environments
• Class B insulation rated for standard ambient temperature service
• Single-phase, 1725 RPM nameplate speed suits most 60 Hz belt-drive and direct-drive loads

Compatibility

Designed as an OEM-style replacement for single-phase, 56H-frame capacitor-start, capacitor-run motors in HVAC, pumping, and light industrial applications requiring 2 HP at 1725 RPM.

Installation Notes

Installation should be performed by a qualified electrician or licensed mechanic in accordance with the National Electrical Code (NEC) and applicable local codes. Disconnect and lock out all power to the equipment before removing the existing motor or making any electrical connections. Verify the supply voltage matches the motor nameplate before connecting leads, and confirm the correct starting capacitor values are in place before energizing. At 42 pounds, use appropriate lifting technique or mechanical assistance when positioning the motor on the mounting base.
