US Motors 9036 PSC TEAO Unit Heater Fan Motor 115V 1/3 HP 1075 RPM
US Motors 9036 PSC TEAO Unit Heater Fan Motor 115V 1/3 HP 1075 RPM
US Motors 9036 PSC TEAO Unit Heater Fan Motor 115V 1/3 HP 1075 RPM

US Motors 9036 PSC TEAO Unit Heater Fan Motor 115V 1/3 HP 1075 RPM

Brand: US MOTORS
SKU: 9036
Availability: In Stock
truck-svgrepo-com

Ships Same Day if Ordered by 12pm
$287.33
$287.33
Manuals:
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Nidec-US Motors 9036 is a PSC TEAO unit heater fan motor designed for HVAC applications. This motor operates at one hundred fifteen volts and provides one third horsepower with a speed of one thousand seventy-five RPM.

  • Continuous duty suitable for use on unit heaters
  • Reversible design for easy installation
  • Includes automatic reset thermal overload protection

Product Highlights

This motor is built to meet specific manufacturer's requirements and features a durable construction to ensure reliability in heating systems.

Product Information

Standard Information

  • Brand: Nidec-US Motors
  • MPN: 9036

Technical Specifications

  • Power: 1/3 HP
  • Voltage: 115V
  • RPM: 1075
  • Phase: 1
  • Amperage: 5.1
  • Frame Size: 48Y
  • Weight: 15.11 lbs
  • Enclosure Type: Totally Enclosed Air Over (TEAO)
  • Shipping Dimensions: 10 x 8 x 8 inches
