US Motors 8558 1/3 HP, 208 to 230 V, 1.9 A, 6-Pole, 1075 RPM, 3-Speed, Double Shaft

Product Description

US Motors 8558 is a condenser fan motor designed for various HVAC applications. This motor operates at a power rating of one-third horsepower and supports a voltage range of two hundred eight to two hundred thirty volts. The product features a totally enclosed air-over design and operates efficiently with a full load amperage of 1.9 amps. The motor runs at a speed of one thousand seventy-five revolutions per minute and includes three speed settings for optimal airflow. It is suitable for use in room air conditioning systems.

• 1/3 horsepower power rating
• Totally enclosed air-over design
• Three-speed operation at 1075 RPM

Product Highlights

This motor is ideal for HVAC technicians who need reliable and efficient motor solutions for air conditioning systems.

Product Information

Standard Information

• Manufacturer: US Motors
• Part Number: 8558

Technical Specifications

• Voltage Rating: 208 to 230 Volt
• Motor FLA: 1.9 Amp
• Number of Speeds: 3
• Speed Rating: 1075 RPM
• Application: Room Air Conditioner
• Enclosure Type: Totally Enclosed, Air-Over
• Power Rating: 1/3 HP
• Size: 5.6 Inch Diameter
• Shaft Size: 0.5 Inch
• Shaft Type: Double
• Number of Poles: 6
