US MOTORS US MOTORS 5432-US Direct Drive Fan and Blower Motor
US MOTORS US MOTORS 5432-US Direct Drive Fan and Blower Motor

US MOTORS 5432-US Direct Drive Fan and Blower Motor

US MOTORS
Brand: US MOTORS
SKU: 5432-US
Availability: Out Of Stock
Final Sale / No Returns
$178.20
$178.20

This is a Final Sale item and cannot be returned or refunded. Exceptions apply for damaged or defective items.

HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The US MOTORS 5432-US is a direct drive fan and blower motor suitable for various applications. This motor operates on 115 V and features ball bearings. The rotor has corrosion protection. With a horsepower range from 1/2 to 1/6 HP, this motor offers reversible operation.

Key Features

  • Ball bearings
  • Rotor corrosion protection
  • Reversible rotation
Technical Specifications
Horsepower
1/2 hp
Kilowatts
0.4
Input Voltage
115 V
Frequency
60 Hz
RPM
1075 rpm
Speeds
4
Motor Poles
6
Phase
1
Rotation
Reversible
Motor Enclosure
TEAO
Maximum Ambient Temperature
104�F (40�C)
Lead Length
36 inches
Capacitor
10/7.5 MFD 370V
Bearings
Ball
Current
7.3 A
Frame Size
48
Shaft Code
Y
Stator Diameter
5.5 inches
Stack
2.25 inches
Mounting Type
Ring/Stud
Motor Type
FHP
Weight
16.04 lbs
Brand
US MOTORS
Manufacturer Part Number
5432-US
