Us Motors 20221 Multi Purpose Motor 208-230V, 1075 RPM 9722

Product Description

The US MOTORS 20221 is a multi-purpose motor designed as a direct replacement for various models including AMANA 201281701 and CENTURY 9722. It is suitable for Lennox, Ducane, and Armstrong units. The motor operates at 208-230V and 1075 RPM.

• Replaces Hundreds of 1/12 to 1/8 HP Applications
• All angle mount
• Class B insulation

Product Highlights

This motor features a reversing plug, is totally enclosed, and has 36-inch leads, making it versatile for different applications.

Product Information

Standard Information

• Brand: US MOTORS
• Manufacturer Part Number: 20221

Technical Specifications

• H.P.: 1/8-1/10-1/12
• Speeds: 1
• Amps: 0.8
• Voltage: 208-230
• RPM: 1075
• Capacitor Required: 5MFD/370V
• Rotation: Reversible
• Bearings: Ball
• Diameter (In.): 5
• Enclosure: Totally Enclosed
• Mounting: Stud or Belly Band
• Service Factor: 1.00
• Shaft Length (In.): 3
• Motor Type: Permanent Split Capacitor
• Frame: 42
• Thermally Protected: None
• Phase: 1
• Shaft Diameter (In.): 1/2
• Shafts: 1
• Hertz: 60
• Shaft Dimension (In.): 1/2 x 3
• Length Less Shaft (In.): 4
