US ALUMINUM CHPTA3630C3 3.0 Ton Horizontal A Coil Evaporator R-32

Product Description

The US ALUMINUM CHPTA3630C3 is a three-ton evaporator coil designed for split system air conditioners and heat pumps. This cased A coil allows horizontal airflow, making it suitable for various installations. With all-aluminum construction, it is optimized for R-32 refrigerant, ensuring efficiency and performance. A thermostatic expansion valve is included, enhancing its operation. The coil’s design supports effective heat transfer and longevity.

• Cased A coil design for effective installation.
• Suitable for horizontal airflow applications.
• Compatible with R-32 refrigerant for energy efficiency.

Product Highlights

This evaporator coil delivers reliable performance in HVAC systems, making it a solid choice for trade professionals focused on quality and efficiency.

Product Information

Standard Information

• Product Type: Evaporator Coil
• Product Line: CHPTA

Technical Specifications

• Coil Type: A Coil
• Configuration: Horizontal
• Refrigerant Type: R-32
• Cooling Capacity: 3.0 Tons
• Cooling BTU: 36000 BTU
• TXV Installed: Yes
• Liquid Line Size: 3/8 Inch
• Suction Line Size: 7/8 Inch
• Cabinet Width: 21 Inches
• Product Width: 30 Inches
• Product Height: 21 Inches
• Product Depth: 21 Inches
• Product Weight: 55 Pounds
• Certifications: AHRI, ETL, ISO
• Casing: Cased
• Material: Aluminum
