US Aluminum CHPTA3630B4 Horizontal Cased Evaporator Coil

Product Description

The US Aluminum CHPTA3630B4 is a horizontal cased evaporator coil suitable for split system air conditioners and heat pumps. This unit features an all-aluminum coil and comes with a factory-installed thermal expansion valve (TXV), ensuring efficient cooling and heating performance. Designed for horizontal airflow applications, it includes a thermoplastic drain pan to handle condensation effectively. Foil-faced insulation is used to minimize moisture buildup within the cabinet.

• All-aluminum evaporator coil for durability.
• Factory-installed thermal expansion valve (TXV) included.
• Optimized for R-410A refrigerant for better efficiency.

Product Highlights

This evaporator coil offers reliable operation in both heating and cooling modes, matching perfectly with standard HVAC setups.

Product Information

Standard Information

• Manufacturer Part Number: CHPTA3630B4
• Product Type: Evaporator Coil

Technical Specifications

• Operating Mode: Heating and Cooling
• Configuration: Horizontal
• Refrigerant Compatibility: R-410A
• Cooling Capacity: 36000 BTU
• Cooling Tonnage: 3 Tons
• Liquid Line Size (OD): 3/8 inches
• Suction Line Size (OD): 7/8 inches
• Coil Width: 17.5 inches
• Product Width: 30 inches
• Product Height: 17.5 inches
• Product Depth: 21 inches
• Product Weight: 51 pounds
• Shipping Weight: 66 pounds
• ETL Listed: Yes
• AHRI Certified: Yes
• Cabinet/Chassis Size: B
