US ALUMINUM CHPTA3026C4 Horizontal Cased Evaporator Coil R-410A

Product Description

The US ALUMINUM CHPTA3026C4 is a horizontal cased evaporator coil intended for split system air conditioners and heat pumps. This unit includes an all-aluminum coil construction, enhancing durability and efficiency. It incorporates a factory-installed thermal expansion valve which optimizes refrigerant flow. The thermoplastic drain pan ensures proper drainage and reduces the risk of corrosion.

• All-aluminum evaporator coil for durability.
• Designed for split system air conditioners and heat pumps.
• Compatible with R-410A refrigerant.

Product Highlights

Featuring foil-faced insulation and a galvanized finish, this evaporator coil is designed for reliable performance and efficiency. It is AHRI certified and ETL listed, ensuring it meets industry standards.

Product Information

Standard Information

• Product Type: Evaporator Coil
• Configuration: Horizontal

Technical Specifications

• Nominal Capacity: 2.5 Tons
• Cooling Capacity: 30000 BTU
• Connection Size: 3/8 inches, 7/8 inches
• Refrigerant Type: R-410A
• Coil Width: 21 inches
• Dimensions: 21 inches H x 26 inches W x 21 inches D
• Shipping Weight: 64 lbs
• AHRI Certified: Yes
• ETL Listed: Yes
