US Aluminum CAPTA3022A3 Evaporator Coil R-32 Cased A Coil

Product Description

The US Aluminum CAPTA3022A3 is an evaporator coil designed for split system air conditioners and heat pumps. This cased A coil is effective in both upflow and downflow configurations. The durability and efficiency of this unit come from its all-aluminum construction, which aids in effective heat transfer. It includes a factory-installed thermal expansion valve (TXV) along with a thermoplastic drain pan for enhanced performance. This coil is compatible with R-32 refrigerant.

• All-aluminum evaporator coil construction
• Includes factory-installed thermal expansion valve (TXV)
• Suitable for both upflow and downflow applications

Product Highlights

The US Aluminum CAPTA3022A3 delivers reliability and efficiency for HVAC systems.

Product Information

Standard Information

• Model Number: CAPTA3022A3
• Type: Evaporator Coil

Technical Specifications

• Product Line: CAPTA
• Refrigerant Type: R-32
• Casing: Cased
• Style: A Coil
• Configuration: Upflow/Downflow
• TXV Installed: Yes
• Cooling Capacity: 2.5 Tons
• Cooling BTU: 30000 BTU
• Suction Connection Size: 3/4 Inch
• Liquid Connection Size: 3/8 Inch
• Cabinet Width: 14 Inches
• Product Height: 22 Inches
• Product Width: 14 Inches
• Product Depth: 21 Inches
• Product Weight: 22 Pounds
• Voltage: 208, 230V
• Frequency: 60 Hz
• Amperage: 10.9A
• Certifications: AHRI, ETL, ISO
