US Aluminum CAPTA1818A3 1.5 Ton Evaporator Coil

Product Description

The US Aluminum CAPTA1818A3 is a cased A-coil evaporator suitable for both upflow and downflow setups in split system air conditioners and heat pumps. It utilizes an all-aluminum construction, which enhances its durability and improves heat transfer efficiency significantly. The unit is designed for compatibility with R-32 refrigerant and comes with a factory-installed thermal expansion valve (TXV) for efficient operation.

• All-aluminum coil construction.
• Designed for upflow or downflow installation.
• Includes factory-installed thermal expansion valve.

Product Highlights

This evaporator coil is intended for both residential and light commercial applications. It is suitable for use with gas furnaces and modular blowers.

Product Information

Standard Information

• Model Number: CAPTA1818A3
• Refrigerant Type: R-32

Technical Specifications

• Cooling Capacity: 1.5 Ton
• Cooling BTU: 18000 BTU
• Configuration: Upflow/Downflow
• Coil Type: A Coil
• TXV Installed: Yes
• Suction Line Size: 3/4 Inch
• Liquid Line Size: 3/8 Inch
• Cabinet Width: 14 Inches
• Dimensions: 14 W x 21 D x 18 H
• Weight: 30 Pounds
