US Aluminum CAPFA3626D6 Cased Upflow/Downflow Indoor Coil

Product Description

The US Aluminum CAPFA3626D6 is a cased indoor coil suitable for split-system air conditioners and heat pumps. This A-coil supports both upflow and downflow installations. It features aluminum tubing and corrugated aluminum fin coils. The cabinet is made from galvanized steel with a protective paint finish for enhanced durability. A thermoplastic drain pan is included to manage condensate effectively.

• Compatible with both upflow and downflow configurations.
• Constructed with aluminum tubing and fin coils for efficient heat transfer.
• Includes a thermoplastic drain pan to handle water condensation.

Product Highlights

This indoor coil is designed for reliable performance and longevity in various HVAC applications.

Product Information

Standard Information

• Product Type: Evaporator Coil
• Country of Origin: United States

Technical Specifications

• MPN: CAPFA3626D6
• Refrigerant Type: R-22 / R-410A
• Casing: Cased
• Style: A Coil
• Configuration: Upflow/Downflow
• Capacity: 3.0 Tons
• Cooling Capacity: 36000 BTU
• Suction Connection Size: 7/8 Inch
• Liquid Connection Size: 3/8 Inch
• Cabinet Width: 24.5 Inches
• Product Height: 26 Inches
• Product Width: 24.5 Inches
• Product Depth: 21 Inches
• Product Weight: 56 lb
• ETL Listed: Yes
• AHRI Certified: Yes
• Orifice Size: 0.065 inches
• Plenum Opening Width: 23.5 inches
• Number of Rows: 3
