US Aluminum CAPFA3626C3 3.0 Ton Upflow/Downflow Cased A Coil with TXV

Product Description

The US Aluminum CAPFA3626C3 is a cased A coil suitable for both upflow and downflow installations in split system air conditioners and heat pumps. Made from all-aluminum material, this coil ensures increased durability and effective heat transfer. It comes with a factory-installed thermal expansion valve (TXV) and is designed for compatibility with R-32 refrigerant. The product features a rust-resistant, thermoplastic drain pan, and a painted cabinet with a nickel gray finish, making it a solid choice for systems with a three-ton capacity.

• All-aluminum evaporator construction
• Designed for upflow and downflow configurations
• Includes factory-installed thermal expansion valve (TXV)

Product Highlights

This evaporator coil is efficient for use in HVAC systems. Its design allows for optimal airflow and heat exchange, catering to diverse installation requirements.

Product Information

Standard Information

• Refrigerant Type: R-32
• Casing: Cased

Technical Specifications

• Product Line: CAPTA
• Refrigerant Type: R-32
• TXV Installed: Yes
• Capacity: 3.0 Tons
• Cooling BTU: 36000 BTU
• Suction Connection Size: 7/8 Inch
• Liquid Connection Size: 3/8 Inch
• Cabinet Width: 21 Inches
• Product Height: 26 Inches
• Product Width: 21 Inches
• Product Depth: 21 Inches
• Product Weight: 36 Pounds
• ETL Listed: Yes
• AHRI Certified: Yes
• ISO Certified: Yes
• Parts Warranty: 10 Limited Years
• Model Number: CAPTA3626C3
• Dimensions: 21 W x 21 D x 26 H
