US ALUMINUM CAPFA3022B3 Evaporator Coil 2.5 Ton R-32

Product Description

The US ALUMINUM CAPFA3022B3 is an evaporator coil designed for cooling applications with a capacity of 2.5 tons. It is suitable for both vertical upflow and downflow installations. This coil is built with an all-aluminum structure which enhances durability and heat transfer efficiency. The unit is encased in a robust cabinet that includes foil-faced insulation to minimize condensation and heat loss. It operates efficiently with R-32 refrigerant and comes with a built-in check flowrator for easy setup.

• AHRI certified and ETL listed
• Includes a DecaBDE-free thermoplastic drain pan
• Single front access panel for easier maintenance

Product Highlights

This evaporator coil is designed for high performance in cooling applications, ideal for HVAC professionals.

Product Information

Standard Information

• Model: CAPFA3022B3
• Product Line: CAPTA

Technical Specifications

• Cooling Capacity: 2.5 Ton
• Cooling BTU: 30000
• Refrigerant: R-32
• Air Flow Direction: Downflow, Upflow
• Casing: Cased
• Style: A Coil
• Configuration: Upflow/Downflow
• TXV Installed: Yes
• Liquid Line Size: 3/8 inch
• Suction Line Size: 3/4 inch
• Product Width: 17.5 inches
• Cabinet Width: 17 1/2 inches
• Product Height: 22 inches
• Product Depth: 21 inches
• Weight: 40 pounds
• ETL Listed: Yes
• AHRI Certified: Yes
• ISO Certified: Yes
• Warranty: 10 Year Parts
