US ALUMINUM CAPFA2422A3 2.0 Ton Upflow/Downflow Cased A Coil

Product Description

The US ALUMINUM CAPFA2422A3 is designed for use in split system air conditioners and heat pumps. It can be used in both upflow and downflow applications. This unit features all-aluminum construction, enhancing durability and heat transfer efficiency. It is specifically optimized for R-32 refrigerant. The cabinet is made from galvanized steel and finished in nickel gray, and it includes a thermoplastic drain pan.

• Cased A coil design for versatile applications
• Compatible with R-32 refrigerant for efficient cooling
• All-aluminum build for durability and effective heat transfer

Product Highlights

This A coil is a critical component for efficient air conditioning systems, promoting effective cooling and heating performance.

Product Information

Standard Information

• Product Category: Evaporator Coil
• Product Line: CAPFA

Technical Specifications

• Refrigerant Type: R-32
• Coil Configuration: A Coil
• Casing: Cased
• Capacity: 2.0 Tons
• Cooling Capacity: 24000 BTU
• Configuration: Upflow/Downflow
• Cabinet Width: 14 Inches
• Product Width: 14 Inches
• Product Height: 22 Inches
• Product Depth: 21 Inches
• Product Weight: 27 Pounds
• Suction Connection Size: 3/4 Inch
• Liquid Connection Size: 3/8 Inch
• Certifications: AHRI, ETL, ISO
