US ALUMINUM CAPFA1818B3 1.5 Ton Cased A Coil

Product Description

The US ALUMINUM CAPFA1818B3 is a cased A coil built for both upflow and downflow setups. This coil is compatible with R-32 refrigerant and constructed entirely of aluminum. It is designed for use with air conditioning or heat pump systems, providing cooling efficiency. The coil features a cabinet width of seventeen and a half inches and has a cooling capacity of one and a half tons, equivalent to eighteen thousand BTU. This unit is certified by AHRI, ETL, and ISO, ensuring reliability and performance. Some models come with a factory-installed Thermal Expansion Valve (TXV).

• Cased A coil design for efficient airflow.
• Compatible with R-32 refrigerant for modern applications.
• Certified by AHRI, ETL, and ISO.

Product Highlights

This coil is suitable for various HVAC setups, offering flexibility in installation and use. Ideal for both residential and commercial applications.

Product Information

Standard Information

• Brand: US ALUMINUM
• MPN: CAPFA1818B3

Technical Specifications

• Cooling Capacity: 1.5 Tons
• BTU Cooling: 18000 BTU
• Refrigerant Type: R-32
• Coil Type: A Coil
• Casing: Cased
• Airflow Orientation: Upflow/Downflow
• Cabinet Width: 17.5 inches
• Product Height: 18 inches
• Product Width: 17.5 inches
• Product Depth: 21 inches
• Product Weight: 19 lbs
• Suction Connection Size: 3/4 Inch
• Liquid Connection Size: 3/8 Inch
• Certifications: AHRI, ETL, ISO
• Voltage: 208V to 230V
• Phase: 1 Ph
• Frequency: 60 Hz
• TXV Installed: No
• Outdoor Approved: No
• Title 20 Compliant: Yes
