US Aluminum CAPFA1818A3 US Aluminum Capfa1818A3 1.5 Ton Cased A Coil

Product Description

The US Aluminum CAPFA1818A3 is a 1.5 ton cased A coil evaporator. It can be installed for either upflow or downflow configurations. This unit features an all-aluminum coil designed for R-32 refrigerant, which includes specialized circuits and manifolds.

• Factory-installed optimized metering device
• Foil-faced insulation to minimize condensation
• Rust-resistant thermoplastic drain pans

Product Highlights

The CAPFA1818A3 is A2L compatible and equipped with a flowrater refrigerant control. Its design includes a galvanized finish that is embossed for added durability.

Product Information

Standard Information

• Brand: US Aluminum
• Product Name: CAPFA1818A3

Technical Specifications

• A2L Compatible: Yes
• BTU Cooling Rating: 18000 Btu/h
• Casing: Cased
• Coil Type: Evaporator
• Collection: CAPFA Series
• Configuration: Downflow, Upflow
• Depth: 21 inches
• ETL Listed: Yes
• Height: 18 inches
• Indoor Outdoor: Indoor
• Liquid Line (OD): 3/8 inches
• Material: Aluminum
• Refrigerant: R-32
• Refrigerant Control: Orifice
• Refrigeration Control Type: Flowrater
• Suction Line (OD): 3/4 inches
• Tonnage: 1.5 Ton
• Weight: 13 lb
• Width: 14 inches
