US Aluminum CAPFA1714B6 1.5 Ton Cased Evaporator Coil

Product Description

The US Aluminum CAPFA1714B6 is a cased evaporator coil designed for use in upflow and downflow applications. This unit works well with split system air conditioners and heat pumps. It includes aluminum tubing, fins, and end plates that enhance heat transfer performance. The coil is compatible with R-410A refrigerant, and in some cases can be used with R-22 refrigerant. The design features a thermoplastic drain pan, and it is finished with a galvanized leather grain surface. This product is both AHRI certified and ETL listed.

• Durable all-aluminum construction.
• Compatible with R-410A refrigerant.
• Includes a thermoplastic drain pan.

Product Highlights

The US Aluminum CAPFA1714B6 is engineered for reliable performance and efficiency in HVAC systems.

Product Information

Standard Information

• Manufacturer: Goodman
• MPN: CAPFA1714B6

Technical Specifications

• Tonnage: 1.5 Tons
• Cooling Capacity: 18000 BTU
• Refrigerant Type: R-410A
• Configuration: Downflow / Upflow
• Coil Type: A Coil
• Casing: Cased
• Liquid Line Size: 3/8 Inch
• Suction Line Size: 3/4 Inch
• Coil Width: 17.5 inches
• Coil Height: 14 inches
• Coil Depth: 21 inches
• Product Weight: 33 lbs
• Shipping Weight: 33 Pounds
• ETL Listed: Yes
• AHRI Certified: Yes
• Orifice Size: 0.051 inches
• Plenum Opening Width: 16.5 inches
• Number of Rows: 3
• Dimensions (L x W x H): 30.00 inches x 24.50 inches x 21.00 inches
