US ALUMINUM CAPEA3022B3 Evaporator Coil - 2.5 Ton

Product Description

The US ALUMINUM CAPEA3022B3 is an evaporator coil designed for split system air conditioners and heat pumps with both upflow and downflow applications. This unit is made from all-aluminum for durability and features high-efficiency aluminum tubing paired with corrugated aluminum fin coils.

• Includes a factory-installed thermal expansion valve (TXV).
• Compatible with R-32 refrigerant.
• Pressure tested for reliable performance.

Product Highlights

This evaporator coil is built for effective heat transfer, essential for maintaining optimal indoor temperatures.

Product Information

Standard Information

• Brand: US ALUMINUM
• MPN: CAPEA3022B3

Technical Specifications

• Product Type: Evaporator Coil
• Product Line: CAPTA
• Coil Type: A Coil
• Configuration: Upflow/Downflow
• Refrigerant Type: R-32
• Capacity: 2.5 Tons
• Cooling BTU: 30000 BTU
• Minimum Cooling Capacity: 30000 BTU
• Casing: Cased
• TXV Included: Yes
• Suction Connection Size: 3/4 Inch
• Liquid Connection Size: 3/8 Inch
• Width: 17 1/2 Inches
• Height: 22 Inches
• Depth: 21 Inches
• Weight: 25 Pounds
• Certifications: AHRI Certified, ETL Listed, ISO Certified
• Parts Warranty: 10 Limited Years
