US Aluminum ASPT47D14 Multi-Position Air Handler

Product Description

The US Aluminum ASPT47D14 is a multi-positional air handler designed for versatility. It operates with R-410A refrigerant and features a stable SmartFrame sub-structure. This model includes mounting locations for components and insulation retention. The unit is equipped with a direct-drive, multi-speed ECM motor for efficient performance. It allows installation in upflow, downflow, or horizontal configurations. The unit is built with a galvanized, leather grain-embossed cabinet.

• Multi-positional airflow configurations
• Factory-mounted TXV valve included
• High-efficiency blower motor

Product Highlights

Ideal for varied installation types in residential or commercial settings.

Product Information

Standard Information

• Refrigerant Type: R-410A
• Product Type: Multi-Positional Air Handler

Technical Specifications

• Cooling Capacity: 3.5 Tons
• Voltage: 208 / 230 / 240 Volts
• Frequency: 60 Hz
• Phase: 1
• Liquid Line Size (OD): 3/8 Inches
• Suction Line Size (OD): 7/8 Inches
• Width: 24.5 Inches
• Depth: 21 Inches
• Height: 53.4375 Inches
• Product Weight: 155 lbs
• Configuration: Downflow / Horizontal / Upflow
• BTU Rating: 42000 Btu/hr Cooling
• SEER Rating: 13
