US Aluminum AMST48CU1300 Air Handler 4.0 Ton

Product Description

The US Aluminum AMST48CU1300 is an air handler designed for the efficient distribution of air. This model uses an all-aluminum evaporator coil and comes with a thermal expansion valve that is factory-installed. It is ideal for cooling and heat pump systems. The ECM blower motor ensures reliable air circulation. Its cabinet is built to minimize noise and air leakage. This product is AHRI certified and ETL listed.

• All-aluminum evaporator coil.
• Multi-speed ECM blower motor.
• Factory-installed thermal expansion valve.

Product Highlights

The US Aluminum AMST48CU1300 supports a variety of applications, making it suitable for both residential and commercial use. It is compatible with central split systems.

Product Information

Standard Information

• Type: Air Handler
• Refrigerant Type: R-32

Technical Specifications

• Cooling Capacity: 4.0 Ton
• Cooling BTU: 48000
• Maximum Air Flow: 1820 CFM
• Minimum Air Flow: 1420 CFM
• Motor Type: ECM
• Blower Motor Type: Multi-Speed
• Mount Type: Multi-Position
• Installation Location: Indoor
• Voltage: 208/230 Volts
• Breaker Size: 15 Amps
• Product Dimensions: 21 inches x 21 inches x 58 inches
• Product Weight: 138 Pounds
• Air Flow Direction: Horizontal, Vertical
• ETL Listed: Yes
• AHRI Certified: Yes
