Uponor LFT4921010SS ProPEX LF Brass Transition Ball Valve 1 inches PEX x 1 inches Copper Press

Product Description

The UPONOR LFT4921010SS ProPEX LF Brass Transition Ball Valve is designed for threaded, press, and flange connections in domestic water and mechanical HVAC piping applications. These full-port ball valves feature stainless-steel stems for reliable, high-flow performance, allowing for faster installations in tight spaces.

• Full port design ensures high flow performance.
• Stainless steel stem provides enhanced durability.
• Suitable for use in domestic water and HVAC systems.

Product Highlights

The UPONOR ProPEX transition ball valve offers reliable performance and efficient installation for various piping applications.

Product Information

Standard Information

• Brand: UPONOR
• Manufacturer Part Number: LFT4921010SS

Technical Specifications

• End Type 1: ProPEX
• End Size 2 [inch|mm]: 1"
• End Type 2: Copper Press
• End Size 1 [inch|mm]: 1"
• Cold working pressure (CWP) [psi]: 250 psi
• Operating Pressure 1 [PSI]: 200 psi
• Operating Temperature 1 [":degree:F]: 200 ":degree:F
• Cv: 22.8
• Material group: LF Brass
• Size: 1" PEX x 1" Copper Press
• Type: Transition Ball Valve
• Body Material: BRASS
• End Style: PEX x Press
• Nominal Size: 1 in
• Port Type: Full
• Pressure Rating: 250 psi
• Temperature Rating: 200 deg F
