United Structural Products A62-09-90VO12-36-G Vertical Outside 90 Degree Elbow

Product Description

This elbow fitting is the United Structural Products A62-09-90VO12-36-G designed for cable tray systems. It is a vertical outside 90-degree elbow made from aluminum. This fitting helps change the direction of cable tray runs in electrical installations. The product features a twelve-inch radius and thirty-six-inch width, beneficial for cable management. This elbow is UL classified under NEC 392.7 and meets CSA Std. C22.2 No. 126. It also meets NEMA standards for cable tray systems.

• Constructed from aluminum with arc-welded joints for added durability.
• Vertical outside 90-degree elbow with a twelve-inch radius and thirty-six-inch width.
• UL classified and certified to meet NEMA and CSA standards.

Product Highlights

Product Information

Standard Information

• Material: Aluminum
• Fitting Type: Vertical Outside 90 Degree Elbow

Technical Specifications

• Bend Angle: 90 Degrees
• Radius: 12 inches
• Width: 36 inches
• Construction: Arc-welded
• Fitting Class: 2
• Hardware Finish: Geomet
• Certifications: UL Classified (NEC 392.7), UL Certified (CSA Std. C22.2 No. 126), NEMA compliant
• Tangents: 3 inches
• Supplied Accessories: One pair of standard splice plates with hardware
